Aries Cerat Contending Reference

The horn load is the most controversial approach in audio playback. Horn load has numerous advantages over any other technology available today. Having an ultra high efficiency means a total lack of distortion of power and distortion compression due to high displacements of the conductor cone. However, a horn not perfectly implemented will sound far from what is called high fidelity.
Building a perfect horn is not an easy matter. It takes time, great space and special drivers. It is not your typical floor support. The special expensive controllers are required, and there are not many with the right tone.
Building a suitable flash for bandwidth with a perfect ending is something that not all take very much into account. The great physical compensations among the controllers make the crossover crossover design incredibly difficult. We believe that we did it possible. And the counting is the test.

High frequency
Using a tape tweeter designed and custom built, with an ultralight aluminum sheet of only 7 mg, with a response of up to 100 kHz, amorphous core transformers / hand-built silver wire, we gave the speaker one Unparalleled quality in high frequency playback. We took one more step and loaded the Tweeter with a tractrix horn that continues its flash up to 360 ° so that there is no present diffraction. Having thus, we gave the tweeter a super dynamic and a perfect transitory response. The performance measurement is absolutely unrivaled and it sounds like nothing you have heard before. Guaranteed.

Medium frequency
The use of a higher quality compression controller, with a 4 'titanium diagram and a magnetic circuit of 11 kg, such as our medium frequency player, requires nothing less than a perfect flared speaker. The Bengal returned to 360th building the horn in our solid wooden-shaped wooden enclosure, we completely eliminate diffraction as a problem. Efficiency is 118 dB / W and attenuated by an impedance adaptation transformer at 104 dB / W
undernight
Most speakers use direct radiation controllers for low media reproduction. We believe that anything other than a horn-loaded controller would compromise the total project. The low media is the basis of music, in all genres.
To cover the range of 110 to 700 Hz, we use a full-size 105-Hz round traction horn, loaded with a powerful 8-inch ultralight controller, with a superfuerte motor and a total mobile mass of only 13 gr, which provides Incredibly detailed and defined graves media. The flash of the TRACTRIX also continues to 360 degrees, and is built in a massive-shaped massive enclosure, to perfectly end the flash of the horn, so that the diffraction is not a problem here either. Efficiency is amazingly 115DB / W and attenuates through an impedance adaptation transformer at 104 dB / W / W. No direct controller is capable of generating the impact, detail and energy, and that horn provides a facility.

Undernight
Most speakers use direct radiation controllers for low media reproduction. We believe that anything other than a horn-loaded controller would compromise the total project. The low media is the basis of music, in all genres.
To cover the range of 110 to 700 Hz, we use a full-size 105-Hz round traction horn, loaded with a powerful 8-inch ultralight controller, with a superfuerte motor and a total mobile mass of only 13 gr, which provides Incredibly detailed and defined graves media. The flash of the TRACTRIX also continues to 360 degrees, and is built in a massive-shaped massive enclosure, to perfectly end the flash of the horn, so that the diffraction is not a problem here either. Efficiency is amazingly 115DB / W and attenuates through an impedance adaptation transformer at 104 dB / W / W. No direct controller is capable of generating the impact, detail and energy, and that horn provides a facility.

Low
The system of speakers is accompanied by a pair of low-sealed cash modules, equipped with two woofers of 15 'each. Woofers have a linear displacement capacity of 34 mm and work flat at 20Hz -6db @ 14Hz) with minimal distortion, giving the capabilities to shake the loudspeaker earth, but at the same time do not interfere with the clarity of the Rest of the audible range with any box noise taken. It is tuned for an optimal transient response, providing an excellent articulated and descriptive low.
Pulse
Bass Module Amplifier
The amplifier to push these massive woofers is a hybrid stereo amplifier designed and internally built. It uses input transformers for land isolation and the elimination of buzzing. It is an adjustable valve crossing, with the valve 6C19P loaded with venum, paraffed another signal transformer, which drives the Dual Class D Amplifier of 400 W, with its dual switched power supplies.
Therefore, the modules can be controlled to offer lower than those that can probably handle, with surprisingly defined low-paced notes. Only the best low frequency players could be part of this 4-way speaker system.
A pair of external crosses is used for the 3 main routes, using copper sheet inductors and high quality polyesterin and teflon capacitors. The crossing is tuned using state-of-the-art equipment and software, as well as the displacement of the controllers. To measure the flat rule of 20 to more than 50 kHz.
